BP-L130E



(1) Integrate SBS-Compliance Gas Gauge IC

(2) Durable impact-resistant PC housing meets UL94-V0 rating

(3) Compliance with UL & CE standard

(4) Splash / scratch-resistant

(5) Support DC Power Jack for travel charger

(6) No memory effect

(7) Terminal laminated with gold to reduce impedance

(8) Ergonomic design for easy grasping

(9) Patented balancer to prolong the life of the Battery Pack


01
Model No.
BP-L130E
02
Video Camera Type
Sony V-Mount
03
Component Cell
Rechargeable Li-Ion Cylindrical Cells(Made By Japanese Manufacturers)
04
Approximate Capacity
130Wh
05
Voltage
AC Output
14.8V
06
Dimension
Thickness/Height
49.5mm
Width
90.5mm
Length
166.5mm
07
Weight
890g
08
Operating Temperature
Charging
-20℃~+45℃ (-4℉~+113℉)
09
Protection
Over-Charge/Over-Discharge/Over-Current/Short-Circuit
10
LEDs Indication
5-LED(100%、 80%'、60%、40%、20%)
11
Typical Runtimes
4 hours @ 30W
12
Applicable Chargers
BPC-2M
13
Maximum Discharge Current
6A
14
Other Major Features
CE-Certified,Rain-Proof,Impact-Resistant,DC Power Jack
