Energy Storage System

1.2KWh



(1) Built-in PC-CHECK software tracks product data for easy maintenance.

(2) Uniformly-designed battery molds make for easy make or maintenance.

(3) BMS gas gauge measures and displays remaining energy capacity.

(4) Protects against electrical overload, short circuiting, over temperature, abnormal AC output and abnormal battery voltage.

(5) Pure sine wave electrical output makes it suitable for all electrical and electronic equipment.


    01
    Model No.
    1.2KWh
    02
    Component Cell
    7799130P
    03
    Weight
    37.2 kgs
    04
    Positive Material
    LiFePO4
    05
    Voltage
    AC Output
    100/110/120V & 50Hz/60Hz
    (Customized & adjustable upon request)
    06
    Output
    Rated Capacity
    1200Wh (51.2V/30Ah)
    Rated Power
    1000W
    Efficiency
    90%
    07
    Dimension
    Thickness/Height
    425mm
    Width
    273mm
    Length
    525mm
    08
    Protection
    Battery low alarm, Battery low shutdown, Output shot, Overload
    09
    Enviroment
    0~+40℃ @ 100% load
    10
    Battery charging time
    About 4~5 hours

    2.4KWh

    (1) With caster and stopper design for easy moving and ...

    3.6KWh

    (1) With caster and stopper design for easy moving and ...

    200W

    (1) Modified sine wave output. (2) 2 times high su...
