120155250N



48 Ah/LiCoxNiyMnzO


01
Model No.
120155250N-AM44E
02
Positive Material
LiCoxNiyMnzO
03
Typical Capacity
48Ah (Min. Capacity)
04
Cycle Life
1C-1C RT >3000
05
Voltage
Average
3.65 V
Max.
4.2 V
Min.
2.8 V
06
Dimension
Thickness/Height
12.5 mm
Width
155 mm
Length
250 mm
07
Weight
<885g
08
Initial Internal Resistance
<1mΩ, 25℃
09
Energy/Rated Capacity
178.8Wh
10
Energy Density
by Weight
202
by Volume
384.6
11
Charge
Max.C-rate
3C
12
Discharge
Max. Continuous C-rate
3C
Transient Peak Current
6C
13
Operating Temperature
Charging
10~45℃
Discharging
-10~45℃
14
Storage Temperature
-20~40℃ Within 1 Years
15
Humidity Range
RH 45~85% Within 1 Years
