7799130N



10.3 Ah/LiCoxNiyMnzO


01
Model No.
7799130N
02
Positive Material
LiCoxNiyMnzO
03
Typical Capacity
10.3 Ah
04
Cycle Life
> 2000
05
Voltage
Average
3.7 V
Max.
4.2 V
Min.
2.8 V
06
Dimension
Thickness/Height
8.00~8.40mm
Width
98.0 mm
Length
130.0 mm
07
Weight
< 218 g
08
Initial Internal Resistance
< 4 mΩ
09
Energy/Rated Capacity
39.4 Wh
10
Energy Density
by Weight
181 Wh/kg
by Volume
388 Wh/L
11
Charge
Max.C-rate
1C
12
Discharge
Max. Continuous C-rate
3C
Transient Peak Current
8C
13
Operating Temperature
Charging
0~45℃
Discharging
-20~55℃
14
Storage Temperature
-20~40℃
15
Humidity Range
< RH 45~85%
